Electric Vehicle Charger 12V15A

Electric Vehicle Charger 12V15A has excellent performance and is suitable for the power grid requirements in Europe and the United States.




Model	ESCH12V5A-I	ESCH12V10A-I	ESCH12V15A-I
Dimensions: Long * wide * high： (mm)	128*123*65		182*123*65
Output maximum current (A)	5	10	15
Maximum power point (W)	60	150	225
Input voltage (VAC)	100-240
Output voltage (VDC)	Lead-acid battery:16V; VRLA:14.4V;(Customizable)
Applicable battery voltage	12 lead-acid battery pack (Customizable)
Maximum efficiency	≥93%
Output voltage regulation precision	±1%
Output current accuracy	±1%
Working temperature	-30℃～45℃
Protection level	IP65
Classes of seismic measure	SAEJ1378
Cooling mode	Self-cooling
Over temperature protection	75℃±5
Input under-voltage protection (VAC)	Under-voltage point 100V
Output over-voltage protection (VDC)	16.5V±1
Output over-current protection (A)	>110%*Maximum charge current
Output short circuit protection	When the output is short-circuited, charger shutdown, and automatic recovery after short-circuit solved.
Battery reverses protection	Charger shutdown and alarm when the wire is connected reversely, it will automatically resume after wiring correctly.



Global voltage compatibility: supports power grid input 100-240V, universal worldwide.

Full power output: provides stable 12V15A output to ensure that electric vehicles are fully charged in the shortest time, meeting your urgent need for efficient charging.

Our Electric Vehicle Charger 12V15A has been finely sprayed three times, and has excellent dust-proof performance, effectively extending service life and improving operational reliability.

Electric Vehicle Charger 12V15A application:

Home charging: makes electric vehicle charging easier.

Commercial charging stations: suitable for public places such as shopping malls, hotels, and parking lots to meet the charging needs of a large number of electric vehicle users.

Suitable for material handling (forklifts, AGV/AMR), electric vehicles (karts, golf carts), aerial work platforms, industrial cleaning machinery, other power tools and electric vehicles, 4. providing a high level of on-board and off-board reliability and charging quality.



With a 3,000 square meter research center.

More than 16 patents, products have passed CE, TUV and UL safety assurance standards



1. Why choose Young Energy?

Young Energy has a young international team and has many years of cooperation experience with more than 10 countries in the field of electric vehicle industrial charger manufacturing.

Young Energy focuses on designing and providing innovative, applicable and competitive industrial battery chargers, DC/DC converters, and wiring harnesses.


2. Does Young Energy accept OEM/ODM orders?

Young Energy certainly accepts OEM/ODM orders based on batches.


3. Where can we get product information?

You can get it through the following website link:

https://youngenergy.com/

You can also contact our international marketing team.


4. What is Young Energy's after-sales policy and period?

For Chinese customers: For conventional products, we promise 1 year warranty as always.

For foreign customers: If there are any quality problems with the product, we will provide free replacement service.


5. Can we cooperate with Young Energy to request agency or exclusive agency?

Of course.


Provide a safer and more reliable charging experience. Choose us to make your electric vehicle charging more efficient and convenient!
